aluminum mobile scaffolding

aluminum mobile scaffolding 1. This series of products subject structure using high-strength aluminum alloy material. 2. The equipment takes up small spaces , light-weight, mobile flexible, looks beautiful. 3.  Electrical control or manual pump control when the electricity is not available. 4. Two control panel: one is hand button, which may be placed in any position on the table railfor the     convenience of operation. The other is fixed on the electric-control box, which is supported with emergency       stop button for prevention of any accident. 5. Easily pushed around to the designated sites. 6. Low energy consumption, no pollution, do no damage to the grounds. 7. The power sources can be 110V 220V 380V AC power, DC power, depending on the local power sources.

type	dimension (mm)	Platform size (mm)	Load capacity (kgs)	Power (kw)	Lift height (m)
SJL0.14(single)	1100x850x1980	600x600	100	0.75	4
SJL0.1-6(single)	1200x850x1980	600x600	100	0.75	6
SJL0.1-8(single)	1300x850x1980	600x600	100	0.75	8
SJL0.110(single)	1400x850x1980	600x600	100	0.75	10
SJL0.2-6(double)	1300x900x1980	1200x600	200	1.5	6
SJL0.2-8(double)	1400x900x1980	1200x600	200	1.5	8
SJL0.210(double)	1900x1000x1980	1500x600	200	1.5	10
SJL0.212(double)	2000x1000x1980	1550x600	200	1.5	12
SJL0.214(double)	2000x1000x2280	1600x600	200	1.5	14
SJL0.216 (double)	3000x1500x2200	1500x600	200	2.2	16
SJL0.2-14(four)	2000x1500x2400	1600x900	250	2.2	14
SJL0.3-16(four)	2500x1300x2400	1800x950	300	2.2	16
SJL0.3-18(four)	2500x1300x3000	1800x950	300	2.2	18
SJL0.3-20(four)	3000x1500x2200	1700x900	300	2.2	20



Contact us if you need more details on aluminum mobile scaffolding. We are ready to answer your questions on packaging, logistics, certification or any other aspects about aerial work platform、adjustable height work platform. If these products fail to match your need, please contact us and we would like to provide relevant information.
