CE approved wheel chair stair lift platform

Product Description

CE approved wheel chair Stair Lift platform       If you have difficulty using stairs, or use a wheelchair or mobility scooter, then a residential vertical lift is a great way to ensure that you can always safely and conveniently enter and exit your home. All of our porch lifts are designed to be completely resistant to the harshest weather conditions and are an affordable alternative to Residential Elevators.

Max travel height

8000mm

Min Platform height

75mm

Configuration

Open through or front and side entrances

Speed

60mm/s

Control voltage

24V/DC

Power Output

2.2kw

Power Input

220V/50HZ (or customized for local power supply)

Drive System

Hydraulic

Control Mode

Inching Switch or Automatic

Drive Control

Self-resetting system

Overload

Protection Over current relay

Material of Platform

Stainless steel

Guard panel & drive Cabinet

(framework)

304 stainless steel



Operation Panel

Spraying plastic

Safety Wane Working Range

75°

Working Condition

Both indoors and outdoors

Working temperature

From -10°~60°C

Installation



 No pit installation, directly fixed to concrete floor

(the concrete floor below the platform shall not be lower than the ground)



Control Device



Calling box (installed on the wall nearby) and remote

controller(Extra optional)



Emergency Stop



The lifting and lowering process can be stopped immediately

by pressing the emergency button.

Safety device

Safety Interlock

Lock the platform when it is out of control



Safety Sensor



The operation must be stopped immediately

the safety edge meets obstacles during operation.



Emergency lowering

The platform can be lowered by opening

hydraulic valve manually or rolling screw rod.

Auto-flap

Turn up after lifting



Contact us if you need more details on CE approved wheel chair stair lift platform. We are ready to answer your questions on packaging, logistics, certification or any other aspects about CE approved wheel chair stair lift platform、CE approved wheel chair stair lift platform. If these products fail to match your need, please contact us and we would like to provide relevant information.
